OMEN MAX Gaming Laptop 16-ah0076TX

Features

Micro-edge; Full-size, per key RGB backlit, shadow black keyboard with numeric keypad and NKRO Anti-Ghosting Key technology; IR; Camera privacy shutter; Trusted Platform Module (Firmware TPM) support; Wi-Fi 7; Integrated 10/100/1000/2500 GbE LAN; HP Extended Range Wireless LAN; 2 USB Type-A 10Gbps signaling rate; 1 AC smart pin; 1 HDMI 2.1; 1 headphone/microphone combo; 1 RJ-45; 2 Thunderbolt™ 4 with USB Type-C® 40Gbps signaling rate (USB Power Delivery 3.1, DisplayPort™ 2.1, HP Sleep and Charge); Ocean-bound plastic in bezel; Keyboard keycaps and scissors contain post-consumer recycled plastic; Recycled metal in cover, base and hinge cap(s)

Laptops

Features Group 1

Get a fresh perspective

Desktop-level performance anywhere

Wide Quad Extended Graphics Array Display

Eyesafe® Certified Display

3ms response time

Windows 11

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08294008.png

High performance

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png

Screen

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05539280.png

[2]

From a rejuvenated Start menu, to new ways to connect to your favorite people, news, games, and content—Windows 11 is the place to think, express, and create in a natural way.

[3]

Level up your PC with advanced performance, enhanced AI, and a CPU designed to defy expectations

[4]

Get lost in the captivating definition with 2560 × 1600 pixels.

[5]

Eyesafe® certified displays meet TÜV low blue light requirements and Eyesafe® standards for protecting your eyes from harmful blue light without distorting colors to reduce eyestrain when working for long periods of time.

[6]

How fast your display’s pixels respond is crucial for a smooth picture. With a 3-millisecond response time, your action-filled content will look crisp and fluid without motion blur.

Featuring

Features Group 2

Flicker-free

16:10 aspect ratio

100% sRGB

Incorporating ocean-bound plastics

Keyboard contains post-consumer recycled plastic

HP Fast Charge

16x10 aspect ratio

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169098.png

Vivid Color

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192784.png

Environmental globe

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201970.png

Fast charging batteries

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08250393.png

[7]

Using DC Dimming technology that controls brightness by adjusting direct current rather than cycling the backlight, we can eliminate screen flickering for more comfortable viewing.

A 16:10 aspect ratio lets you see more of your content with less scrolling.

Showcase your creations in all their colors on the 100% sRGB display for maximum color broadness and accuracy.

[8]

HP incorporates increasing amounts of recycled, renewable, and non-virgin raw materials. Built with the environment in mind, this product includes a percentage of ocean-bound plastic in the design.

[9]

We're bringing a more thoughtful design to our keyboards by using post-consumer recycled plastic in the design.

[10]

When your laptop is low on power, no one has time to wait hours to recharge. Power down your device and go from 0 to 50% charge in approximately 30 minutes.

Features Group 3

[13]

Enjoy a smooth wireless experience with a Wi-Fi 7 (2x2) and Bluetooth® 5.4 combo.

HP True Vision FHD IR camera

Thunderbolt™ 4 with USB™ Type-C®

McAfee® LiveSafe™

HP Audio Boost

Audio tuned by HyperX

Wireless

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png

Webcam

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201986.png

USB-C®

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08380672.png

http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c06061804.png

Audio boost

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05205157.png

[11]

[12]

Log in safely through Windows Hello with the infrared sensor. With an 88-degree, wide-angle field of view, you can video chat with your entire family or group of friends in stunning detail.

The latest Thunderbolt™ solution lets you power your device or connect up to two 4K displays with a single cable and blazing 40Gbps signaling rate.

Free 12-month subscription of McAfee® LiveSafe™ service included. McAfee® LiveSafe™ service enriches your digital life by protecting your data, identity and all your devices so you can connect with confidence.

Take your audio experience to the next level with smart amplification technology giving you loud, clear and dynamic sound.

Immerse yourself in the sweet sounds of audio mixed and tuned by HyperX.

Flex Value Proposition

Helping protect our shared future

HP has included recycled content into over 95% of new PC’s and Displays since 2020.

Features Group 4

Dual channel memory

HP Imagepad with multi-touch gesture

HP Imagepad

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169220.png

With dual channel technology, two channels work simultaneously to double the communication speed between the memory controller and the RAM increasing system performance.

This true multi-touch touchpad supports four finger gestures and lets you scroll, zoom, and navigate with a simple touch.

Key Selling Points

Performance you control

Throttle less and carry more with the latest Intel® Core™ Ultra CPUs[1] and next-gen NVIDIA® RTX™ graphics.

Put your throttling on ice

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201996.png

Self-cleaning fans, a vapor chamber, and liquid metal ensure your laptop stays cool and reduces maintenance.

Instant pair with HyperX

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08205649.png

Seamlessly connect up to three compatible HyperX devices to your laptop at once with Instant Pair.

Light the way you play

https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08380671.png

Customize your lattice-less RGB keyboard and other lighting options in OGH to represent your unique style.

Product Description

The OMEN 16 MAX gaming laptop provides unparalleled performance both at-home or on-the-go. With next-gen NVIDIA® GPUs and Intel® Core™ Ultra CPUs[1], a new Unleashed Mode for manual overclocking, and a thermal architecture built to cut down on both throttling and long term wear, dedicated gamers can achieve their best for years to come.

Throttle less and cary more with the latest Intel® Core™ Ultra CPUs[1], next-gen NVIDIA® graphics, and a thermal architecture that can actually keep up with your gameplay.

Built to break limits

Delivering unparalleled performance that pushes your power past limits while staying cool for uninterrupted gaming.

Target Market

The OMEN MAX 16 was specifically built to cut down on thermal throttling while maximizing game performance, so dedicated gamers can reach their max potential.

Technical Specifications

Manufacturer Warranty	1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
Color	Shadow black
Product color	Shadow black aluminum in cover and base, light bar, RGB in keyboard frame, black chrome logo
Product design	Sandblasted and paint finish
UPC number	198990587134
Battery capacity	83
Battery capacity uom	Wh
Battery cells number	6
Battery recharge time	Supports battery fast charge: approximately 50% in 30 minutes
Battery type	Li-ion polymer
Battery type	6-cell, 83 Wh Li-ion polymer
Power supply type	330 W AC power adapter
Camera brand	HP True Vision
Camera Infrared	IR
Camera microphone	integrated dual array digital microphones
Camera resolution standard	FHD
Camera resolution (vertical)	1080p
Camera	HP True Vision 1080p FHD IR camera with temporal noise reduction and integrated dual array digital microphones
Product type	Laptops
Series name	OMEN MAX (16) 40.64 cm
Sub brand	OMEN MAX
Environmental certification	ENERGY STAR® certified;EPEAT® registered
Sustainability specifications	Ocean-bound plastic in bezel; Keyboard keycaps and scissors contain post-consumer recycled plastic; Recycled metal in cover, base and hinge cap(s)
Ports	2 USB Type-A 10Gbps signaling rate; 1 AC smart pin; 1 HDMI 2.1; 1 headphone/microphone combo; 1 RJ-45; 2 Thunderbolt™ 4 with USB Type-C® 40Gbps signaling rate (USB Power Delivery 3.1, DisplayPort™ 2.1, HP Sleep and Charge)
Bluetooth version	Bluetooth® 5.4
Ethernet (RJ-45)	1
Expansion slots	2 M.2 (SSD)
HDMI out – version	2.1
HDMI –out	1
Headphone/microphone combo	1
Network interface	Integrated 10/100/1000/2500 GbE LAN
Thunderbolt™ 4 ports	2
USB Type-A	2
Wireless antenna	2x2
Wireless model	BE200
Wireless supplier	Intel®
Wireless standard	Wi-Fi 7
Wireless	Intel® Wi-Fi 7 BE200 (2x2) and Bluetooth® 5.4 wireless card
Wireless Note	HP Extended Range Wireless LAN
Package depth, metric (most common size)	42.8
Package height, metric (most common size)	42.8
Package width, metric (most common size)	9.4
Package depth, imperial (most common size)	16.85
Package dimensions (W x D x H)	9.4 x 42.8 x 33.2 cm
Package height, imperial (most common size)	13.07
Packaging unit of measure (imperial)	in
Packaging unit of measure (metric)	cm
Package width, imperial (most common size)	3.7
Dimensions (W x D x H)	14.04 x 10.59 x 0.9 in (front); 14.04 x 10.59 x 0.98 in (rear)
Dimensions (W x D x H)	35.65 x 26.9 x 2.29 cm (front); 35.65 x 26.9 x 2.48 cm (rear)
Aspect ratio	16:10
Brightness	500 nits
Display bezel	Micro-edge
Display brightness	500
Display brightness uom	nits
Display	40.6 cm (16") diagonal WQXGA display
Color gamut	100% sRGB
Display	40.6 cm (16") diagonal, WQXGA (2560 x 1600), 60-240 Hz, 3 ms response time, IPS, micro-edge, anti-glare, Low Blue Light, 500 nits, 100% sRGB
Display panel technology	IPS
Display refresh rate	240
Display refresh rate uom	Hz
Display response time	3
Display response time uom	ms
Display resolution standard	WQXGA
Display resolution (pixels)	2560 x 1600
Display size (diagonal, imperial)	16
Display size (diagonal, metric)	40.6
Display size (diagonal, metric) uom	cm
Display size (diagonal) uom	"
Display size (diagonal)	40.6 cm (16")
Display surface treatment	Anti-glare
Flicker-free	Yes
Screen-to-body ratio (without speakers)	88.81%
Touchscreen	No
Maximum resolution	2560 x 1600
Screen size (in)	16
Storage	1 TB
Cloud service	100 GB Dropbox storage for 3 months
Internal Storage	1 TB PCIe® Gen5 NVMe™ Performance M.2 SSD
Storage capacity	1
Storage capacity uom 01	TB
Storage form factor 01	M.2
Storage interface 01	PCIe® Gen 5
Storage interface protocol 01	NVMe™
Storage memory technology 01	Performance
Storage type	SSD
Storage type 01	SSD
Energy Usage CO2e (kg)	77
End of Life CO2e (kg)	1
Production CO2e (kg)	119
Total CO2e (kg)	200
Total CO2e (kg) note	A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in units of CO2 equivalence. Calculations are done in accordance with ISO 14040 & ISO 14044. Individual values may not sum to total due to rounding.
Transportation CO2e (kg)	0.3
Form factor	Standard laptop
Country of origin	China(ACJ)
Graphics	NVIDIA® GeForce RTX™ 5080
Graphics	Discrete
Graphics card brand	NVIDIA®
Graphics card family	GeForce
Graphics card memory size	16
Graphics card memory size uom	GB
Graphics card memory type	GDDR7
Model Number	RTX™ 5080
Graphics (discrete)	NVIDIA® GeForce RTX™ 5080 Laptop GPU (16 GB GDDR7 dedicated)
Weight (kg)	2.68
Memory layout (slots & size)	2 x 16 GB
Memory module type	SODIMM
Memory size	32
Memory size uom	GB
Number of memory slots	2
Memory speed	5600
Memory speed uom	MT/s
RAM (GB)	32
Memory and storage	32 GB memory;1 TB SSD storage
Memory type	DDR5
Number of User-accessible Memory Slots	2
Memory	32 GB DDR5-5600 MT/s (2 x 16 GB)
Memory Note	Transfer rates up to 5600 MT/s.
Usage	Maximum gaming performance
Audio	Dual speakers; HP Audio Boost; HyperX; DTS:X Ultra™
Keyboard	Full-size, per key RGB backlit, shadow black keyboard with numeric keypad and NKRO Anti-Ghosting Key technology
Keyboard backlight	RGB backlit
Keyboard backlit zone	per key
Keyboard color	Shadow black
Keyboard keypad	Numeric keypad
Keyboard size	Full-size
Keyboard technology	NKRO Anti-Ghosting Key technology
Pointing device	HP Imagepad
Input devices	IR thermal sensor
Artificial intelligence	AI PC
Chipset	Intel® HM870
Neural Processing Unit	Intel® AI Boost (13 NPU TOPS)
Processor Brand	Intel®
Processor cache	36 MB L3
Processor family	Core™ Ultra 9
Processor frequency technology	Intel® Turbo Boost Technology
Processor maximum frequency	5.4
Processor maximum frequency uom	GHz
Processor model	275HX
Processor core	24
Processor family	Intel® Core™ Ultra 9 processor
Processor	Intel® Core™ Ultra 9 275HX (up to 5.4 GHz with Intel® Turbo Boost Technology, 36 MB L3 cache, 24 cores, 24 threads)
Processor NPU Tops	13
Processor threads	24
Processor type	Intel Core Ultra 9
Product display name	OMEN MAX Gaming Laptop 16
Product number	B90KQPA
Security management	Camera privacy shutter; Trusted Platform Module (Firmware TPM) support
Operating system	Windows 11 Home
Support service included	HP 1 year 3 day Onsite Notebook Service. For terms and conditions, please visit https://h20195.www2.hp.com/v2/GetPDF.aspx/4AA3-8282EEIN & https://www8.hp.com/h20195/v2/getpdf.aspx/4AA5-7123EEIN.pdf
Package weight	4.74 kg
Weight	6.1 lb
Weight	2.76 kg
